Cleanness |
|
|
High wear resistant PU minimizes dusting and is especially suitable for clean rooms, food and beverage industry. |
|
● |
Non-Slip |
|
|
Belts teeth mesh with pulleys, assuring the smooth transmission against tooth jump, friction and speed variation. |
|
● |
Free of Maintenance |
|
|
Compared with chains or gears, the cost of lubrication and maintenance is few. |
|
● |
Low Pre-tension |
|
|
Only low initial tensioning, motor and bearing loads are minimized, enjoying longer belt life. |
|
●
|
Constant Tension |
|
|
No retensioning required. |
|
● |
A wide Range of Load Capacities and Speeds
|
|
|
-
Speeds range from 0 to over 20000 RPM.
-
Ideal for low, medium and high power range. For example, sustained transmission of high torque level at low speed, high power transmission at high speed or shock loads.
-
High degree of efficiency: allows friction-free drives with an efficiency of 99% and also lowering the operation costs.
|
|
● |
Dimensional Stability |
|
|
Excellent structure and bonding , constant belt thickness and width enable smooth running. |
|
● |
Oil Resistance
|
|
|
Conditionally resistant to oils, grease and fuel. |
|
● |
Temperature Range
|
|
|
Under room temperature, it is from -20°C to 95°C. |
|
● |
Climate Resistance |
|
|
-
Suitable for tropical climates.
-
Resistant to aging, ozone, hydrolysis and UV.
|
|
● |
Bending Resistance |
|
|
-
Special and high quality component.
-
Belts are suitable for bending applications.
|
|
● |
Environmental Friendly |
|
|
-
Certificated by RoHS compliance.
-
Low dusting, provided non-marking structure.
-
Free carbon black.
|
|
● |
Antistatic |
|
|
-
Antistatic belt is made-to-order
-
The whole one is electronically conductive and conforms to ≤ 109 Ω
-
Resistance remains steady and will not lower following a long-run operation
|
|
● |
Acid and Alkali Resistance |
|
|
Conditionally resistant to acid and alkali |
|
● |
Wear Resistance |
|
|
Ten times higher than rubber belts. |
|
● |
Anti-solvent |
|
|
Conditionally anti-solvent. |
|
● |
Hardness |
|
|
Standard hardness is 83 Shore A. 60, 73, 78, 90 and 95 Shore A are made-to-order. |
|
● |
Minimal space and weight |
|
|
High power rate transmission allows the use of small pulley diameters and short center distances. This enables compact and light-weight drives |
|
● |
Various specifications |
|
|
-
A wide range of pitches, profiles and width are available.
-
Customized width enables the costs down.
|
|
● |
Applications |
|
|
-
The property of timing belt is precision. All pitches of the whole belt are reached high accuracy. Therefore, it is ideal for high torque transmission, linear positioning, smooth running and high rotational speeds.
-
Small pitches are ideal for smooth operation and precision positioning under light load.
|
|
● |
Large pitches are suitable for large transmission ratios, positional and angular accuracy, and synchronous conveying. For instances: |
|
|
-
Automatic sliding doors
-
Material flow
-
At low temperatures, in clean rooms and in the food industry
-
Office machinery: printers, plotters, copiers
-
EDP equipment
-
Textile machinery
-
Wood processing machinery
-
Machine tools
-
Pumps
-
Compressors
-
Monery handling
-
Data storage equipment
-
Medical equipment
-
Food processors
-
DC stepper/ servo
-
Centrifuge
-
Vending machines
-
Vacuum cleaners
|
