Free of maintenance |
|
|
Compared with chains or gears, the cost of lubrication and maintenance is few. |
|
● |
Non-slip: |
|
|
Belts teeth mesh with pulleys, assuring the smooth transmission against tooth jump, friction and speed variation. |
|
● |
Low pre-tension |
|
|
Only low initial tensioning, motor and bearing loads are minilized, enjoying longer belt life. |
|
● |
Load capacities and speeds |
|
|
1. Ideal for low, medium and high power range. For example, sustained transmission of high torque level at low speed and high power transmission at high speed or shock loads. |
|
|
2. High degree of efficiency: allows friction-free drives with an efficiency of 99%, also lowering the operation costs. |
|
● |
Superior dimensional stability |
|
|
Excellent structure and bonding , constant belt thickness and width enable smooth running. |
|
● |
Cleanness |
|
|
High wear resistant polyurethane (PU) minimizes dusting and is especially suitable for clean rooms, food and beverage industry. |
|
● |
Oil resistance |
|
|
Conditionally resistant to oils, grease and fuel. |
|
● |
Temperature range |
|
|
Under room temperature, it is from -20°C to 80°C (It allows 110°C in a flash.). |
|
● |
Climate resistance |
|
|
Suitable for tropical climates |
|
|
Resistant to aging, ozone, hydrolysis and UV. |
|
● |
Environmental friendly |
|
|
Certificated by REACH Commission. Low dusting, provided non-marking structure. Free of carbon black. |
|
● |
Antistatic |
|
|
Antistatic belt is made-to-order. The whole one is electronically conductive and conforms to ≤ 106 Ω. Resistance remains steady and will not lower following a long-run operation. |
|
● |
Acid and alkali resistance |
|
|
Conditionally resistant to acid and lye. |
|
● |
Wear-resistance |
|
|
Ten times higher than rubber belts. Constant coefficient of friction. |
|
● |
Anti-solvent |
|
|
Conditionally anti-solvent. |
|
● |
Hardness |
|
|
Standard hardness is 83 Shore A. 60, 73, 78, 90 and 95 Shore A are made-to-order. |
|
● |
Space saving and energy efficiency |
|
|
Allowing compact drives with small pulley diameters and short center distances. A belt with low inertia enables a light-weight and space-saving design. Therefore, it lowers manufacturing cost and power consumption. |
|
● |
Various specifications |
|
|
Standard color is black. Customized width enables the costs down. |
|
● |
Applications |
|
|
1. Reversing drives, e.g., printing machines, office machinery and fitness equipment.
2. Linear and rotational positioning, e.g., machine tools, linear positioning system and coordinate measuring machines.
3. Linear motion, e.g., automatic sliding doors, automated warehouse conveyors and |
